8.4.11.14.2 Through Fault (If Enabled)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
V/Hz Protection
Breaker Failure
Thermal Overload
Through Fault

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Through Fault.
Press the Right arrow key () to move to the next option.
Through Fault
TF Enable
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the TF Enable can set i.e. Disabled /
Enabled.
Note: When set as Enabled.
Press the Right arrow key () to move to the next option.
TF Enable
TF Monitoring
W1
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the TF Enable can set i.e. W1 / W2 / Bias.
Press the Minus / Down arrow key (- /) to move to the next
option.
TF Enable
TF I>
1.00 pu
Range 0.08 – 20pu
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the TF I> can set. The setting range is from
0.08 to 20 pu in step of 0.01 pu.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
