8.4.4.3.2 Setting Group (If set as TimeEnabled)
MEASURMENTS
GLOBAL

CB CONTOL
REPORTING
Password protected window for “Global” setting. i.e. General
Settings, Setting Group, Port F, Port 1, PORT R , IRIG Port,
Angle Calibration, Disturbance, Display Contrast & Date and
Time.
Press the Right arrow key () to move to the next option.
General Settings
Settings Group

PORT F
PORT 1
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Settings Group.
Password protected window for “Settings Group” i.e.
Factory Defaults, Active Group, Copy From, Copy To, G1, G2,
G3 and G4.
Press the Right arrow key () to move to the next option.
Setting Group
Factory Defaults
No Operation
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Factory Defaults can be set i.e. All
Settings, No Operation, Setting Group 1, Setting Group 2,
Setting Group 3 and Setting Group 4.
Press the Minus / Down arrow key (- /) to move to the next
option.
Setting Group
Active Group
G1
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Active Group can be set i.e. G1 / G2 /
G3 / G4.
Press the Minus / Down arrow key (- /) to move to the next
option.
Setting Group
Copy from
G1
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Copy from can be set i.e. G1 / G2 / G3 /
G4.
Press the Minus / Down arrow key (- /) to move to the next
option.
