Ashida ADR233B - Page 266

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 266 of 479
ADR233B
Setting Group
Copy to
No Operation
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Copy to can be set i.e. No Operation /
G1 / G2 / G3 / G4.
Press the Minus / Down arrow key (- /) to move to the next
option.
Setting Group
G1
TimeEnabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the G1 can be set i.e. Disabled / Enabled /
TimeEnabled.
Note: When set as TimeEnabled
Press the Minus / Down arrow key (- /) to move to the next
option.
Setting Group
GroupChange Delay
5.0 s
Range 0 – 400 s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Groupchange Delay can be set.
The setting range is from 0 to 400s in step of 0.1s.
Press the Minus / Down arrow key (- /) to move to the next
option.
Setting Group
G2
TimeEnabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the G2 can be set i.e. Disabled / Enabled /
TimeEnabled.
Note: When set as TimeEnabled
Press the Minus / Down arrow key (- /) to move to the next
option.
Setting Group
GroupChange Delay
5.0 s
Range 0 – 400 s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Groupchange Delay can be set.
The setting range is from 0 to 400s in step of 0.1s.
Press the Minus / Down arrow key (- /) to move to the next
option.
