11.6 Testing of Binary Output
Output Contact Test:
• Assign all Relay outputs for any of the inputs.
• Then Apply voltage to respective Binary input so that respective relay is operated.
• After tripping, check continuity in between NC, NO and C output contact terminals.
• After that remove voltage of Binary input and respective relay is reset.
• Again check the continuity in between NC, NO and C output contact terminal.
Slots
Binary Output Terminals
For M0 For E0 For B0
Output1 J1 – J2 C16 – C18 C17 – C18
Output2 J3 – J4 C17 – C19 C19 – C20
Output3 J5 – J6 C20 – C22 – C24 C21 – C22
Output4 J7 – J8 C21 – C23 – C25 C23 – C24
Output5 J9 – J10 C26 – C28 C26 – C27 – C28
Output6 J11 – J12 C27 – C29 C29 – C30
Output7 J13 – J14 C30 – C40 C31 – C32
Output8 J15 – J16 – J17 C31 – C40 C33 – C34
Output1 K1 – K2 C32 – C40 C35 – C36
Output2 K3 – K4 C33 – C40 C37 – C38
Output3 K5 – K6 C34 – C40 C39 – C40
Output4 K7 – K8 C35 – C40 -
Output5 K9 – K10 C36 – C40 -
Output6 K11 – K12 C37 – C40 -
Output7 K13 – K14 C38 – C40 -
Output8 K15 – K16 – K17 C39 – C40 -
Output1 L1 – L2 * - -
Output2 L3 – L4 * - -
Output3 L5 – L6 * - -
Output4 L7 – L8 * - -
Output5 L9 – L10 * - -
