Ref ID : ADR233B/IM/TC
Rev No. : 05
Page No. : 477 of 479
ADR233B
Output6 L11 – L12 * - -
Output7 L13 – L14 * - -
Output8 L15 – L16 – L17 * - -
Output1 M1 – M2 * - -
Output2 M3 – M4 * - -
Output3 M5 – M6 * - -
Output4 M7 – M8 * - -
Output5 M9 – M10 * - -
Output6 M11 – M12 * - -
Output7 M13 – M14 * - -
Output8 M15 – M16 – M17 * - -
* Available only in M19” version
11.7 LED Test
• Assign LED-L1 to LED-L8 (Green & Red) for any Binary inputs.
• Apply voltage to respective Binary input so the respective LED is operated.
• After that remove voltage of Binary input and respective LED is off
