ADR233B
Note : The W1 Phase OC settings of IP>2 Enable and IP>3 Enable for Definite Time Curve is similar
to W1 Phase OC setting of IP>1 Enable.
Note : The Phase OC settings of W2 Phase OC is similar to W1 PhaseOC
8.4.11.6 Ground OC
8.4.11.6.1 Ground OC (If Disabled)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Ph differential
REF
Phase OC
Ground OC

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Ground OC.
Press the Right arrow key () to move to the next option.
Ground OC
Ground OC

Editable Setting
Password protected window for “Ground OC” setting i.e.
IE>1 Enable, IE>2 Enable and IE>3 Enable can be set as
Disabled / Enabled.
Press the Right arrow key () to move to the next option.
Ground OC
IE>1 Enable
Disabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 Enable can be set i.e. Disabled /
Enabled.
Note: When set as Disabled
Press the Minus / Down arrow key (- /) to move to the next
option.
