ADR233B
Ref ID : ADR233B/IM/SS
Rev No. : 05
Page No. : 179 of 479
The 2nd harmonic blocking is applied only when the fundamental current is above 2nd Harm Thresh
and below I> UB2H setting. The reset levels are 95% of these thresholds
Note : Sequence OC setting for Seq.I>2 & Seq.I >3 of Winding 1 and Sequence OC setting for Seq.I>1
Seq.I>2 & Seq.I>3 of Winding 2 are similar to Sequence OC Seq.I >1 settings.
6.8.8 Under Voltage
Sr. No Parameter Defaults setting Setting / Ranges
1.
Password 0000 0000 to zzzz/ZZZZ
This setting is to disable or enable the Under Voltage protection function.
2.
V<1 Enable Disabled Disabled/Enabled
This setting is to off the Under Voltage protection function or can be selected as AND Logic
3.
V<1 10 % 5% to 95% step of 1%
The setting is to set the pickup value above which Under Voltage function will operate
4.
tV<1 Delay 0.1 s 0 to 99.0s in step of 0.1 s
This setting is to set the definite time delay for Under Voltage protection function.
6.8.9 Over Voltage
Sr. No Parameter Defaults setting Setting / Ranges
1.
Password 0000 0000 to zzzz/ZZZZ
This setting specifies to enter the set password
2.
V>1 Enable Disabled Disabled/Enabled
This setting is to disable or enable the Over Voltage protection function.
3.
V>1 105 % 105% to 150% step of 1%
The setting is to set the pickup value above which Under Voltage function will operate
4.
tV>1 Delay 0.1 s 0 to 99.0s in step of 0.1 s
This setting is to set the definite time delay for Under Voltage protection function.
6.8.10 V/Hz Protection
Sr. No Parameter Defaults setting Setting / Ranges
1.
Password 0000 0000 to zzzz/ZZZZ
This setting specifies to enter the set password.
2.
V/Hz-1 Protection Disabled Disabled/Enabled
This setting is to enable or disable the first stage of V/Hz protection.
3.
V/Hz Level1 105% 100 to 200% in step of 1%
The setting is to set operating rane of V/Hz protection.
4.
tV/Hz Level1 100.0s 0.1 to 400s in step of 0.1s
