ADR233B
Error Log

By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select “Error Log”
Press the Right arrow key () to move to the next option.
Maint Rec Num =
70
Error Cod = 00000002
RTC Error
This window shows number of maintenance record with error
code & error type
Press the Right arrow key () to move to the next option.
Errorcod : 00000002
RTC Error
21/06/2017
10:39:25:527
This window shows Date and Time of the Error.
Press the Right arrow key () to move to the Main Menu.
MEASURMENT
GLOBAL
CB CONTOL
REPORTING

8.4.6.5 CB Data
8.4.6.5.1 To View – CB Data
MEASURMENT
GLOBAL
CB CONTOL
REPORTING

This menu is to view “Reporting” i.e. Event, Status, Fault
Record, Error Log, CB Data and Alarm Record.
Press the Right arrow key () to move to the next option.
CB Data

By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select “CB Data”
Press the Right arrow key () to move to the next option.
TC = 0
W1–BOT = 0 mSec
W1–BOC = 0
This window shows Tripping counter, Breaker Opening Time
and Breaker Operation Counter
Press the Minus / Down arrow key (- /) to move to the next
option.
