ADR233B
Doc ID : ADR233B/IM/01
Ref ID : ADR233B/IM/I&S
Rev No. : 05
Page No. : 38 of 479
Drawing References:
I.
BASIC
: For Cabinet Type - MAC01302
: For Back Connections – Non-Draw out - ACD02703
: For Typical External Connections – Non-Draw out - ACD02803
: For Back Connections – Plug-in - ACD03503
: For Typical External Connections – Plug-in - ACD03603
II.
ENHANCE
: For Cabinet Type - MAC01964
: For Back Connections (16DO&10DI) – Plug-in - ACD03903
: For Typical External Connections (16DO&10DI) – Plug-in - ACD03404
: For Back Connections (11DO&10DI) – Plug-in - ACD04103
: For Typical External Connections (11DO&10DI) – Plug-in - ACD03804
III.
MODULAR
14”
: For Cabinet Type - MAC01967
: For Back Connections - ACD03103
: For Typical External Connections - ACD03203
IV.
MODULAR
19”
: For Cabinet Type - MAC01953
: For Back Connections - ACD02903
: For Typical External Connections - ACD03003
1.5 Typical Tests Information
The Relay Confirm to following standard:
Electromagnetic Compatibility Type Test:
Sr. No. Standard Test
I.
High Frequency Disturbance Test IEC60255-22-1, IEC60255-26 (ed3)
II.
Electrostatic Discharge Test- Direct
Application
IEC60255-22-2, IEC60255-26 (ed3)
III.
Fast Transient Disturbance Test IEC60255-22-4, IEC60255-26 (ed3)
IV.
Surge Immunity Test IEC60255-22-5, IEC60255-26 (ed3)
V.
Power Frequency Immunity Test IEC60255-22-7, IEC60255-26 (ed3)
VI.
Power Frequency Magnetic Field Immunity
Test
IEC61000-4-8, IEC60255-26 (ed3)
VII.
Pulse Magnetic Field Immunity Test IEC61000-4-9, IEC60255-26 (ed3)
VIII.
Radiated Electromagnetic Field Disturbance
Test
IEC60255-22-3, IEC60255-26 (ed3)
IX.
Conducted Disturbance Induced By Radio
Frequency Field
IEC60255-22-6, IEC60255-26 (ed3)
