Ashida ADR233B - REF (if Highz)

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 322 of 479
ADR233B
REF Enabled
2nd HrmREF BLK
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 2nd HrmREF BLK can be set i.e.
Disabled/Enabled.
Note: When set as Enabled
Press the Right arrow key () to move to the next option.
REF Enabled
2nd Hrm Threshold
20 %
Range 5 – 70%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 2nd Hrm Threshold can be set.
The setting range is from 5 to 70% in step of 1%.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTIONS
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

8.4.11.4.3 REF (If HighZ)
PROTECTIONS
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
