ADR233B
Equipment Data
Ph Differential
REF

Phase OC
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select REF.
Press the Right arrow key () to move to the next option.
REF
REF Enable

HighZ
Editable Setting
Password protected window for “REF” setting i.e. REF
Enable Disabled/HighZ/LowZ, (If LowZ: Ref. Winding, Isr>1,
Isr>2, Slope1, Slope2, tIsr>) or (If HighZ: Isr>) and 2nd Hrm
REF BLK (2nd Hrm Threshold.)
Note: When set as HighZ
Press the Right arrow key () to move to the next option.
REF Enabled
Isr>
0.10 A
Range 0.05 – 1A
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Isr> can be set.
The setting range is from 0.05 to 1A in step of 0.01A
Press the Minus / Down arrow key (- /) to move to the next
option.
REF Enabled
2nd Hrm REF BLK
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 2nd Hrm REF BLK can be set i.e.
Disabled/Enabled.
Note: When set as Enabled
Press the Right arrow key () to move to the next option.
REF Enabled
2nd Hrm Threshold
20 %
Range 5 – 70%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 2nd Hrm Threshold can be set.
The setting range is from 5 to 70% in step of 1%.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
