ADR233B
Note : The W1 Phase OC settings of IP>2 Enable and IP>3 Enable for all IEEE / US Curves is similar
to W1 Phase OC setting of IP>1 Enable.
Note : The Phase OC settings of W2 Phase OC is similar to W1 PhaseOC.
8.4.11.5.4 W1 Phase OC (If Definite Time is selected)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Equipments Data
Ph differential
REF
Phase OC

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Phase OC.
Press the Right arrow key () to move to the next option.
Phase OC
W1 Phase OC

W2 Phase OC
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select W1 Phase OC.
Password protected window for “W1 Phase OC” setting i.e.
IP>1 Enable, IP>2 Enable and IP>3 Enable can be set as
Disabled / Enabled.
Press the Right arrow key () to move to the next option.
W1 Phase OC
IP>1 Enabled
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 Enabled can be set i.e. Disabled /
Enabled.
Note: When set as Enabled
Press the Right arrow key () to move to the next option.
