Ashida ADR233B - Page 333

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 333 of 479
ADR233B
W1 Phase OC
IP>1 Curve
Definite Time
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 Curve can be set i.e. Definite
Time / IEC S Inverse / ST Inverse 1.3S / IEC V Inverse / IEC
E Inverse / UK LT Inverse / IEEE M Inverse / IEEE V Inverse /
IEEE E Inverse / US Inverse / US ST Inverse.
Note: When set as Definite Time Curve.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Phase OC
IP>1
1.00 A
0.05 – 35.00 xIn
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 can be set.
The setting range is from 0.05 to 35.00 xIn in step of 0.01 xIn.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Phase OC
t IP>1 DT Delay
1.00 s
Range 0 – 1899.9s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tIP>1 DT Delay can be set.
The setting range is from 0 (Inst) to1899.9s in step of 0.01s.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Phase OC
IP>1 D/O Char
DT
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IP>1 D/O Char can be set i.e. Disabled /
DT
Note: If Disabled the D/O Characteristics function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF DT
W1 Phase OC
t IP>1 D/O Delay
0.01 S
Range 0 – 100s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tIP>1 D/O Delay can be set.
The setting range is from 0s to 100s in step of 0.01s
Press the Minus / Down arrow key (- /) to move to the next
