ADR233B
Ref ID : ADR233B/IM/I&S
Rev No. : 05
Page No. : 28 of 479
1.3 Ordering Information
1.3.1 Basic Version
Ordering Information ADR233B (Basic Version)
1-4 5 6 7 8 9 10 11 12 13 14 15
Model 233B X X X X X X X X X X X
Example 233B B 0 0 2 0 0 0 0 2 0 H
TRANSFORMER
PROTECTION
Sub Type
Basic Version B
Variant
Standard 0
Language
English 0
Protocol
IEC 103 0
MODBUS RTU 1
IEC 61850 2
MODBUS TCP 4
IEC104 6
CT / PT & RTD
Default: 7CT, CT Selection: 1A/5A, PT: 110V L-L 0
Digital Outputs
Basic - 11DO 0
Digital Inputs
Basic - 12DI 0
DI Setting Threshold
18VDC 0
35VDC 1
77VDC 2
154VDC 3
Auxiliary Supply
24 – 230 VDC / VAC 2
Cabinet Details
Non Draw Out 0
Plug In 2
Communication Ports
Disable / No Rear Port 0
RS-422 Rear Port A
