Ashida ADR233B - Page 29

ADR233B
Doc ID : ADR233B/IM/01
Ref ID : ADR233B/IM/I&S
Rev No. : 05
Page No. : 29 of 479
RS-485 Rear Port B
10/100 Base-T Ethernet RJ45 Rear Port C
10/100 Base-T Ethernet RJ45 Rear Port & RS-422 Rear Port D
10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port E
DUAL 10/100 Base-T Ethernet RJ45 Rear Port F
DUAL 10/100 Base-T Ethernet RJ45 Rear Port & RS-422 Rear Port G
DUAL 10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port H
1.3.2 Enhance Version:
Ordering Information ADR233B (Enhanced Version)
1-4 5 6 7 8 9 10 11 12 13 14 15
Model 233B X X X X X X X X X X X
Example 233B E 0 0 2 0 1 0 2 2 2 M
TRANSFORMER
PROTECTION
Sub Type
Enhanced Version E
Variant
Standard 0
Language
English 0
Protocol
IEC 103 0
MODBUS RTU 1
IEC 61850 2
MODBUS TCP 4
IEC104 6
CT / PT & RTD
Default: 7CT, CT Selection: 1A/5A, PT: 110V L-L 0
Digital Outputs
Enhanced - 16DO 0
Enhanced - 11DO 1
Digital Inputs
Enhanced - 10DI 0
DI Setting Threshold
18VDC 0
35VDC 1
77VDC 2
154VDC 3
