Ashida ADR233B - Page 30

ADR233B
Doc ID : ADR233B/IM/01
Ref ID : ADR233B/IM/I&S
Rev No. : 05
Page No. : 30 of 479
Auxiliary Supply
24 – 230 VDC / VAC 2
Cabinet Details
Non Draw Out 0
Plug In 2
Communication Ports
Disable / No Rear Port 0
RS-485 Rear Port B
10/100 Base-T Ethernet RJ45 Rear Port C
10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port E
DUAL 10/100 Base-T Ethernet RJ45 Rear Port F
DUAL 10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port H
RS-485 Rear Port + IRIGB Port I
10/100 Base-T Ethernet RJ45 Rear Port + IRIGB Port J
10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port + IRIGB Port K
DUAL 10/100 Base-T Ethernet RJ45 Rear Port + IRIGB Port L
DUAL 10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port + IRIGB Port M
DUAL FO Ethernet Rear Port & RS-485 Rear Port N
Single FO Ethernet Rear Port & Single 10/100 Base-T RJ45 + RS-485 Rear Port O
DUAL FO Ethernet Rear Port & RS-485 Rear Port + IRIGB Port P
Single FO Ethernet Rear Port & Single 10/100 Base-T RJ45 + RS-485 Rear Port + IRIGB Port Q
1.3.3 Modular Version:
Ordering Information ADR233B (Modular Version)
1-4 5 6 7 8 9 10 11 12
13 14 15
Model 233B X X X X X X X X
X X X
Example 233B M 0 0 2 0 1 1 2
2 2 M
TRANSFORMER PROTECTION
Sub Type
Modular Version M
Variant
Standard 0
Language
English 0
Protocol
IEC 103 0
MODBUS RTU 1
IEC 61850 2
