ADR233B
Ref ID : ADR233B/IM/I&S
Rev No. : 05
Page No. : 31 of 479
MODBUS TCP 4
IEC104 6
CT / PT & RTD
Default: 7CT, CT Selection: 1A/5A, PT: 110V PH-PH
0
Digital Outputs
16DO 1
24 DO 2
32 DO 3
Digital Inputs
16DI 1
24 DI 2
32 DI 3
DI Setting Threshold
18VDC 0
35VDC 1
77VDC 2
154VDC 3
Auxiliary Supply
24 – 230 VDC / VAC 2
Cabinet Details
Modular Version M-14 2
Modular Version M-19 3
Communication Ports
Disable / No Rear Port 0
RS-485 Rear Port B
10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port E
DUAL 10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port H
RS-485 Rear Port + IRIGB Port I
10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port + IRIGB Port K
DUAL 10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port + IRIGB Port M
DUAL FO Ethernet Rear Port & RS-485 Rear Port N
Single FO Ethernet Rear Port & RS-485 Rear Port O
DUAL FO Ethernet Rear Port & RS-485 Rear Port + IRIGB Port P
Single FO Ethernet Rear Port & RS-485 Rear Port + IRIGB Port Q
DUAL 10/100 Base-T Ethernet RJ45 Rear Port & RS-485 Rear Port (with PRP / HSR) R
DUAL FO Ethernet Rear Port & RS-485 Rear Port (with PRP / HSR) S
To Next Page
