Ashida ADR233B - Ground OC (if IEEE; US Curve Is Selected)

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 339 of 479
ADR233B
Ground OC
IE>1 UB2H
4.0 A
4.0 – 32.0 xIn
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 UB2H can be set.
The setting range is from 4.0 to 32.0 xIn in step of 0.1 xIn.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Note : The Ground OC settings of IE>2 Enable and IE>3 Enable for all IEC Curves is similar to
Ground OC setting of IE>1 Enable.
8.4.11.6.3 Ground OC (If IEEE / US Curve is selected)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Ph differential
REF
Phase OC
Ground OC

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Ground OC.
Press the Right arrow key () to move to the next option.
