ADR233B
Ground OC
IE>1 TMS
0.01
Range 0.01 – 1.5
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 TMS can be set.
The setting range is from x0.01 to x1.5 in step of 0.01
Press the Minus / Down arrow key (- /) to move to the next
option.
Ground OC
IE>1 D/O Char
DT
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 D/O Char can be set i.e. Disabled /
DT.
Note: If Disabled the D/O Characteristics function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF DT
Ground OC
t IE>1 D/O Delay
0.01 s
Range 0 – 100s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tIE>1 D/O Delay can be set.
The setting range is from 0 to 100s in step of 0.01s
Press the Minus / Down arrow key (- /) to move to the next
option.
Ground OC
IE>1 2H BLK
Enabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 2H BLK can be set i.e. Disabled /
Enabled.
Note: If Disabled the IE>1 2H BLK function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF Enabled
Ground OC
IE>1 2H Thresh
5 %
Range 5 – 70%
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 2H Thresh can be set.
The setting range is from 5% to 70% in step of 1%
Press the Minus / Down arrow key (- /) to move to the next
option.
