ADR233B
option.
REF Enabled
Isr>1
0.20 pu
Range 0.05 – 1pu
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Isr>1 can be set.
The setting range is from 0.5 to 1pu in step of 0.01pu.
Press the Minus / Down arrow key (- /) to move to the next
option.
REF Enabled
Isr>2
1.0 pu
Range 0.1 – 10pu
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Isr>2 can be set.
The setting range is from 0.1 to 10pu in step of 0.1pu.
Press the Minus / Down arrow key (- /) to move to the next
option.
REF Enabled
Slope1
30 %
Range 0 – 150%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Slope1 can be set.
The setting range is from 0 to 150% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
REF Enabled
Slope2
80 %
Range 15 – 150%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Slope2 can be set.
The setting range is from 15 to 150% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
REF Enabled
tIsr>
0.01 s
Range 0 – 10s
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tIsr> can be set.
The setting range is from 0 to 10s in step of 0.1s.
Press the Minus / Down arrow key (- /) to move to the next
option.
