Time Delay at 10 times of W23Io>1 setting ________ms ________ms
11.5 Testing of Binary Input
1. The Binary inputs will be tested by applying 24-230V DC voltage to respective binary input
terminals.
2. Observe binary input status on LCD display in Status menu of REPORTING
3. Following are the binary inputs terminals
Slots
Binary Input Terminals
For M0 For E0 For B0
Input1 H1 – H2 C7 – C8 C3 – C7
Input2 H3 – H4 C7 – C9 C3 – C8
Input3 H5 – H6 C7 – C10 C3 – C9
Input4 H7 – H8 C7 – C11 C3 – C10
Input5 H9 – H10 C7 – C12 C3 – C11
Input6 H11 – H12 C7 – C13 C3 – C12
Input7 H13 – H14 C7 – C14 C3 – C13
Input8 H15 – H16 C7 – C15 C3 – C14
Input1 I1 – I2 C1 – C2 (TC1) C3 – C15
Input2 I3 – I4 C3 – C4 (TC2) C3 – C16
Input3 I5 – I6 - C4 – C5
Input4 I7 – I8 - C4 – C6
Input5 I9 – I10 - -
Input6 I11 – I12 - -
Input7 I13 – I14 - -
Input8 I15 – I16 - -
Input1 N1 – N2 * - -
Input2 N3 – N4 * - -
Input3 N5 – N6 * - -
Input4 N7 – N8 * - -
Input5 N9 – N10 * - -
Input6 N11 – N12 * - -
Input7 N13 – N14 * - -
Input8 N15 – N16 * - -
Input1 O1 – O2 * - -
Input2 O3 – O4 * - -
Input3 O5 – O6 * - -
Input4 O7 – O8 * - -
Input5 O9 – O10 * - -
