Phase Protection Test: -
Settings W1IP>1: ________ W1IP>1 TMS =: _______
W2IP>1: ________ W2IP>1 TMS =: _______
Threshold Theoretical Value Relay Value
W1IP>1 Threshold ________A ________A
W1IP>1 Drop Threshold ________A ________A
W2IP>1 Threshold ________A ________A
W2IP>1 Drop Threshold ________A ________A
W1IP>1Time Delay Setting = _________
IDMT Characteristics = ________ 10 Times _________Sec. (take value from selected curve)
W2IP>1Time Delay Setting = _________
IDMT Characteristics = ________ 10 Times _________Sec. (take value from selected curve)
Threshold Relay
Time Delay at 2 times of W1IP>1 setting ________ms ________ms
Time Delay at 10 times of W1IP>1 setting ________ms ________ms
Time Delay at 2 times of W2IP>1 setting ________ms ________ms
Time Delay at 10 times of W2IP>1 setting ________ms ________ms
Earth Protection Test: -
Settings W13Io>1: ________ W1 3Io>1 TMS = :_______
W23Io>1: ________ W2 3Io>1 TMS = :_______
Threshold Theoretical Value Relay Value
W13Io>1 Threshold ________A ________A
W13Io>1 Drop Threshold ________A ________A
W23Io>1 Threshold ________A ________A
W23Io>1 Drop Threshold ________A ________A
W13Io>1 Time Delay Setting = _________
IDMT Characteristics = __________ 10 Times _________Sec.
W23Io>1 Time Delay Setting = _________
IDMT Characteristics = __________ 10 Times _________Sec.
Threshold Relay
Time Delay at 2 times of W13Io>1 setting ________ms ________ms
Time Delay at 10 times of W13Io>1 setting ________ms ________ms
Time Delay at 2 times of W23Io>1 setting ________ms ________ms
