Ashida ADR233B - Page 297

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 297 of 479
ADR233B
CT/VT RATIO
VT Primary
1 KV
Range 0.1 – 800KV
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the VT Primary can be set.
The setting range is from 0.1KV to 800KV in step of 0.01KV.
Press the Minus / Down arrow key (- /) to move to the next
option.
CT/VT RATIO
VT Selection
Line to Line
Read-only setting
This window shows the VT Selection (Line to Line).
Press the Minus / Down arrow key (- /) to move to the next
option.
CT/VT RATIO
VT Secondary
110V
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the VT Secondary can be set i.e. 110V /
120V
Press the Minus / Down arrow key (- /) to move to the next
option.
CT/VT RATIOS
Setting Values
Secondary
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Setting Values can be set i.e. Primary /
Secondary.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
