Ashida ADR233B - Page 296

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 296 of 479
ADR233B
CT/VT RATIO
W2 Ph CT Secondary
1 A
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W2 Ph CT Secondary can be set i.e.
1Amp. / 5Amp.
Press the Minus / Down arrow key (- /) to move to the next
option.
CT/VT RATIO
W2 Ph CT Primary
10 A
Range 10 – 5000A
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W2 Ph CT Primary can be set.
The setting range is from 10 to 5000A in step of 1A.
Press the Minus / Down arrow key (- /) to move to the next
option.
CT/VT RATIO
EF CT Secondary
1 A
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the EF CT Secondary can be set i.e. 1Amp.
/ 5Amp.
Press the Minus / Down arrow key (- /) to move to the next
option.
CT/VT RATIO
EF CT Primary
10 A
Range 10 – 5000A
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the EF CT Primary can be set.
The setting range is from 10 to 5000A in step of 1A.
Press the Minus / Down arrow key (- /) to move to the next
option.
CT/VT RATIO
CT Star Point
Towards Object
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the CT Star Point can be set i.e. Towards
Object / Away From Object.
Press the Minus / Down arrow key (- /) to move to the next
option.
