ADR233B
W1 – Ia MAG :
0 A
W1 – Ia ANG :
0 Deg
This window shows Secondary Current and angle of Phase A
of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – Ib MAG :
0 A
W1 – Ib ANG :
0 Deg
This window shows Secondary Current and angle of Phase B
of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – Ic MAG :
0 A
W1 – Ic ANG :
0 Deg
This window shows Secondary Current and angle of Phase C
of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – Iab MAG :
0 A
W1 – Iab ANG :
0 Deg
This window shows Secondary Phase to Phase Current and
angle of AB of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – Ibc MAG :
0 A
W1 – Ibc ANG :
0 Deg
This window shows Secondary Phase to Phase Current and
angle of BC of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – Ica MAG :
0 A
W1 – Ica ANG :
0 Deg
This window shows Secondary Phase to Phase Current and
angle of CA of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – I1 P MAG :
0 A
W1 – I2 P ANG :
0 Deg
This window shows Primary Current of Positive and Negative
sequence component current of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
