Ashida ADR233B - Page 251

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 251 of 479
ADR233B
W1 – I1 MAG :
0 A
W1 – I1 ANG :
0 Deg
This window shows Secondary Current and angle of Positive
sequence component of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – I2 MAG :
0 A
W1 – I2 ANG :
0 Deg
This window shows Secondary Current and angle of Negative
sequence component of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – I0 MAG :
0 A
W1 – I0 ANG :
0 Deg
This window shows Secondary Current and angle of Zero
sequence component of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – 3I0 MAG :
0.00 A
W1 – Ia RMS :
0.00 A
This window shows Secondary Current that is multiplied by
three times of Zero sequence component and RMS Current in
Phase A of Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 – Ib RMS :
0.00 A
W1 – Ic RMS :
0.00 A
This window shows RMS Current in Phase B and Phase C of
Winding 1 (W1).
Press the Minus / Down arrow key (- /) to move to the next
option.
W2 – IA MAG :
0 A
W2 – IB MAG :
0 A
This window shows Primary Current in Phase A & Phase B of
Winding 2 (W2).
Press the Minus / Down arrow key (- /) to move to the next
option.
W2 – IC MAG :
0 A
IN MAG :
0 A
This window shows Primary Current in Phase C of Winding 2
(W2) & Neutral.
Press the Minus / Down arrow key (- /) to move to the next
option.
