Ashida ADR233B - Page 284

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 284 of 479
ADR233B
W1 CB CONTROL

W2 CB CONTROL
Password protected window for “W1 CB Control” setting i.e.
TCS Enable Disabled/Enabled, TCS Delay, CB Open S’vision
Disabled/Enabled, CB Open Time, CB Open Alarm
Disabled/Enabled, CB Rated I, m constant, CB Oper. Counter,
CB Control By Disabled/Local/Remote/Local+Remote, t CB
Open Pulse & t CB Close Pulse.
Press the Right arrow key () to move to the next option.
W1 CB CONTROL
TCS Enable
Logic Low
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the TCS Enable can be set. i.e. Disabled /
Logic Low / Logic High.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 CB CONTROL
TCS Delay
0.5 S
Range 0.1 – 10s
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the TCS Delay can be set. The setting range
is from 0.1s to 10.00s in step of 0.1s.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 CB CONTROL
CB Open S’vision
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the CB Open Supervision can be set i.e.
Disabled / Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 CB CONTROL
CB Open Time
300 ms
Range 50 – 1000ms
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the CB Open Time can be set.
The setting range is from 50 to 1000ms in step of 10ms.
Press the Minus / Down arrow key (- /) to move to the next
option.
