Ashida ADR233B - Page 285

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 285 of 479
ADR233B
W1 CB CONTROL
CB Open Alarm
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the CB Open Alarm can be set i.e. Disabled /
Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 CB CONTROL
CB Oper. Counter
20000
Range 10 - 50000
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the CB Oper. Counter can be set.
The setting range is from 10 to 50000 in step of 1.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 CB CONTROL
CB Rated I
100 A
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the CB Rated I can be set.
The setting range is from 1 to 5000 A instep of 1A.
Press the Right arrow key () to move to the next option.
W1 CB CONTROL
m constant
1
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the m constant can be set.
The setting range is from 0.1 to 5 in step of 0.001.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 CB CONTROL
CB Control by
Local + Remote
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the CB Control By can be set i.e. Disabled /
Local / Remote / Local + Remote.
Press the Minus / Down arrow key (- /) to move to the next
option.
