ADR233B
W1 Residual OC
3Io>1 Curve
IEC S Inverse
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>1 Curve can be set i.e. Definite
Time / IEC S Inverse / ST Inverse 1.3S / IEC V Inverse / IEC
E Inverse / UK LT Inverse / IEEE M Inverse / IEEE V Inverse /
IEEE E Inverse / US Inverse / US ST Inverse.
Note: When set as IEC Curve.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Residual OC
3Io>1
1.00 A
0.10 – 4.00 xIn
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>1 can be set.
The setting range is from 0.05 to 4.00 xIn in step of 0.01 xIn.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Residual OC
3Io>1 TMS
0.100
Range 0.01 – 1.5
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>1 TMS can be set.
The setting range is from x0.01 to x1.5 in step of 0.001
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Residual OC
3Io>1 D/O Char
DT
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>1 D/O Char can be set i.e. Disabled /
DT.
Note: If Disabled the D/O Characteristics function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF DT
W1 Residual OC
t3Io>1 D/O Delay
0.01 s
Range 0 – 100s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the t3Io>1 D/O Delay can be set.
The setting range is from 0 to 100s in step of 0.01s
Press the Minus / Down arrow key (- /) to move to the next
