ADR233B
Ref ID : ADR233B/IM/SS
Rev No. : 05
Page No. : 167 of 479
6.1.8 Display contrast
Sr. No Parameter Defaults setting Setting / Ranges
1.
Contrast Set 50% Read-only
This setting is to adjust the display contrast.
6.1.9 DATE AND TIME settings
Sr. No Parameter Defaults setting Setting / Ranges
1.
Password 0000 0000 to zzzz/ZZZZ
This setting is to enter the set password.
2.
Local Time Enable Fixed Fixed / Flexible / Disabled
Setting to turn on/off local time adjustments.
Fixed - A local time zone adjustment can be defined using the Local Time offset setting and all
interfaces will use local time.
Flexible - A local time zone adjustment can be defined using the Local Time offset setting and each
interface can be assigned to the UTC zone or local time zone with the exception of the local interfaces
which will always be in the local time zone.
Disabled - No local time zone will be maintained. Time synchronization from any interface will be used
to directly set the master clock and all displayed (or read) times on all interfaces will be based on the
master clock with no adjustment.
3.
Local Time Offset 0 Mins -720 to + 720 in step of 15 Mins
This setting is to specify an offset of -12 to +12 hrs in 15 minute intervals for local time zone. This
adjustment is applied to the time based on the master clock which is UTC/GMT
4.
DST Enable Disabled Read-Only
5.
RP Time Zone Local UTC/ Local
The UTC / Local (Setting for the rear port 1 interface to specify if time synchronization received will be
local or universal time co-ordinated.)
6.
SET Hours 11 * 00 to 23 Hrs in step of 1.
Hour setting is needed when relay is not connected to SCADA system
7.
SET Minutes 35 * 00 to 59 Mins in step of 1.
Minutes setting is needed when relay is not connected to SCADA system
8.
SET Seconds 54 * 00 to 59Sec. in step of 1.
Seconds setting is needed when relay is not connected to SCADA system
9.
SET Date 13 * 01 to 31 Days in step of 1.
Date needed when relay is not connected to SCADA system
10.
SET Month 04 * 01 to 12 Months in step of 1.
Month needed when relay is not connected to SCADA system
11.
SET Year 18 * 00 to 99 Years in step of 1.
Year needed when relay is not connected to SCADA system
Note: * Relay shows current time, set into the relay
