configuration setting, then all associated settings and signals are available in Group3 setting menu.
10.
GroupChange Delay 5.0s 0 to 400.0s in step of 0.1s
This setting defines duration for which the setting of changed group remains activated
11.
G4 Disabled Disabled / Enabled / Time Enabled
This setting is to enable / disable the setting group 4. If the setting group 4 is enabled from the
configuration setting, then all associated settings and signals are available in Group 4 setting menu.
12.
GroupChange Delay 5.0s 0 to 400.0s in step of 0.1s
This setting defines duration for which the setting of changed group remains activated
6.1.3 PORT F
Sr. No Parameter Defaults setting Setting / Ranges
1.
Unit ID 1 Read only
This setting is to set the unique address for the relay such that only one relay is accessed by master
station software.
2.
Baud Rate 57600 Read only
This setting is to control the communication speed between relay and master station. It is important that
both relay and master station are set at the same speed setting.
3.
Set Parity None Read only
This setting is to control the Rear Port parity format used in the data frames. It is important that both
relay and master station are set with the same parity setting.
6.1.4 PORT 1
Sr. No Parameter Defaults setting Setting / Ranges
1.
Unit ID 1 1 to 247 in step of 1
This setting is to set the unique address for the relay such that only one relay is accessed by master
station software.
2.
IP address 000.000.000.000 0 to 255 in step of 1
This setting is to set the IP address of the Relay
3.
Subnet mask 000.000.000.000 0 to 255 in step of 1
This setting is to set the subnet mask of the Relay
4.
Default gateway 000.000.000.000 0 to 255 in step of 1
The setting is to set the default gateway
5.
Pri. SNTP 000.000.000.000 0 to 255 in step of 1
This setting is to set pri. SNTP
6.
Sec. SNTP 000.000.000.000 0 to 255 in step of 1
This setting is to set Sec. SNTP
7.
Protocol Disabled Disabled / Enabled
This setting is to Enable the communication Protocol
8.
Ethernet Mode Dual Dual / fixed
This setting is used to set the Ethernet Mode as Dual or Fixed.
