This is read only setting, used to display the Serial No of the relay.
18.
Software Version 233BM0020123HV5.03 Read only
This is read only setting, used to display the software version of the relay.
19.
Hardware Version V1.00 Read only
This is read only setting, used to display the Hardware version of the relay.
20.
Equipment Transformer Read only
This is read only setting, used to display the equipment.
21.
Virtual Scheme 1 Disabled Disabled / Enabled
This setting is used to enable Virtual bit in AProLogic
22.
Virtual Scheme 2 Disabled Disabled / Enabled
This setting is used to enable Virtual bit in AProLogic
6.1.2 Settings Group:
Sr. No Parameter Defaults setting Setting / Ranges
1.
Factory Default No Operation No Operation / All Settings / Setting
Group 1 / Setting Group 2 /Settings
Group 3 / Settings Group 4
This setting shows factory Default as default setting.
To restore the default values to the settings in any Group settings, set the ‘Factory Defaults to the
relevant Group number. Alternatively it is possible to set the ‘restore defaults’ to ‘all settings’ to restore
the default values to all of the IED’s settings, not just the Group settings.
The default settings will be placed in Flash and will only be used by the IED after they have been
confirmed by the user.
2.
Active Group G1 G1 / G2 / G3 / G4
This setting is to select the active setting group.
3.
Copy From G1 G1 / G2 / G3 / G4
This setting allows settings to be copied from a selected setting group.
4.
Copy To No operation No operation / G1 / G2 / G3 / G4
This setting allows settings to be copied to a selected setting group
5.
G1 Enabled Disabled / Enabled / Time Enabled
This setting is to enable / disable the setting group 1. If the setting group 1 is enabled from the
configuration setting, then all associated settings and signals are available in Group 1 setting menu.
6.
GroupChange Delay 5.0s 0 to 400.0s in step of 0.1s
This setting defines duration for which the setting of changed group is remains activated
7.
G2 Disabled Disabled / Enabled / Time Enabled
This setting is to enable / disable the setting group 2. If the setting group 2 is enabled from the
configuration setting, then all associated settings and signals are available in Group 2 setting menu.
8.
GroupChange Delay 5.0s 0 to 400.0s in step of 0.1s
This setting defines duration for which the setting of changed group remains activated
9.
G3 Disabled Disabled / Enabled / Time Enabled
This setting is to enable / disable the setting group 3. If the setting group 3 is enabled from the
