ADR233B
Ref ID : ADR233B/IM/SS
Rev No. : 05
Page No. : 163 of 479
6 SETTING SHEET
6.1 GLOBAL
6.1.1 General Settings:
Sr. No Parameter Defaults setting Setting / Ranges
1.
Password 0000 0000 to zzzz/ZZZZ
This setting specifies to enter set password. 0000 is default set password.
2.
TID Transformer ID xxxxxxxxxxxxxxxx
This setting specifies to enter Transformer Identification Setting.
3.
SID SubStn_ID xxxxxxxxxxxxxxxx
This setting specifies to enter Station Identification Setting.
4.
Phase Ref PT PT / W1-Rph / W2-Rph
This setting specifies to select the Phase reference for angle measurement.
5.
System Frequency 50Hz 50Hz / 60Hz
This setting specifies to select the system frequency.
6.
Opto I/P Supply DC DC / AC
This setting specifies to select opt coupler i/p to status as AC/DC.
7.
W1 CB Operation No Operation CB Open / CB Close / No Operation
This setting is used to operate CB through HMI.
8.
W2 CB Operation No Operation CB Open / CB Close / No Operation
This setting is used to operate CB through HMI.
9.
PB-1 Operation No Operation No operation / Enabled
This setting is used to operate assign output by using local switch-PB1.
10.
tPB-1 Pulse 0.50 S 00.10 to 50.00 sec in step of 0.01s
This setting defines the duration of the PB-1 pulse for a manual operation of output
11.
PB-2 Operation No Operation No operation / Enabled
This setting is used to operate assign output by using local switch-PB2.
12.
tPB-2 Pulse 0.50 S 00.10 to 50.00 sec in step of 0.01s
This setting defines the duration of the PB-2 pulse for a manual operation of output
13.
Config Port PORT F Read only
This setting specifies to select communication port for 103 communication through RTV2.
14.
Timesync Master PORT 1 PORT F / PORT 1 / PORT R / IRIG-B
This setting is used to set the timesync Master
15.
Description ASHIDA ADR233B M0 Read only
This is read only setting, used to display the type of the relay.
16.
Model Number ADR233BM005033123M Read only
This is read only setting, used to display the model no of the relay.
17.
Serial Number xxx233BMxxxxxxxxx Read only
