Ashida ADR233B - Page 270

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 270 of 479
ADR233B
PORT 1
Subnet Mask =
255.255.255.000
Range 0 – 255
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Subnet Mask can be set in each decimal
section. The setting range is from 0 to 255. As per Editing
Password setting.
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT 1
Default Gateway =
255.255.255.000
Range 0 – 255
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Default Gateway can be set in each
decimal section. The setting range is from 0 to 255. As per
Editing Password setting.
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT 1
Pri. SNTP =
000.000.000.000
Range 0 – 255
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Pri. SNTP can be set in each decimal
section. The setting range is from 0 to 255. As per Editing
Password setting.
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT 1
Sec. SNTP =
000.000.000.000
Range 0 – 255
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Sec. SNTP can be set in each decimal
section. The setting range is from 0 to 255. As per Editing
Password setting.
Press the Minus / Down arrow key (- /) to move to the next
option.
PORT 1
Protocol
Disabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Protocol can be set i.e. Disabled /
Enabled.
Press the Minus / Down arrow key (- /) to move to the next
