Note: The settings for Breaker Failure i.e. W2 50 BF is similar to W1 50 BF Settings.
8.4.11.13 Thermal Overload
8.4.11.13.1 To Set – Thermal Overload (If Disabled)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Over Voltage
V/Hz Protection
Breaker Failure
Thermal Overload

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Thermal Overload.
Press the Right arrow key () to move to the next option.
Thermal Overload
THOL Enable
Disabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the THOL Enable can set i.e. Disabled / W1
and W2.
Note: When set as Disabled.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
