ADR233B
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

8.4.11.13.2 To Set – Thermal Overload (If Enabled)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Over Voltage
V/Hz Protection
Breaker Failure
Thermal Overload

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Thermal Overload.
Press the Right arrow key () to move to the next option.
Thermal Overload
THOL Enable
W1
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the THOL Enable can set i.e. Disabled / W1
and W2.
Note: When set as W1.
Press the Right arrow key () to move to the next option.
THOL Enabled
Ith>Trip
100 %
Range 5 – 400%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Ith>Trip can be set.
The setting range is from 5 to 400 % in step of 1 %.
Press the Minus / Down arrow key (- /) to move to the next
option.
