ADR233B
THOL Enabled
Ith> Alarm
70 %
Range 50 – 100 %
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Ith> Alarm can be set.
The setting range is from 50 to 100% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
THOL Enabled
T
20 Mins
Range 1 – 200Mins
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the T can be set.
The setting range is from 001 to 200mins in step of 1mins.
Press the Minus / Down arrow key (- /) to move to the next
option.
THOL Enabled
Service Factor
1.05
Range 1 – 1.5
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Service Factor can be set.
The setting range is from 1.00 to 1.50 in step of 0.01.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Note: The settings for Thermal Overload i.e. W2 is similar to W1 Settings.
