W1 Residual OC
3Io>1 Enable
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>2 Enable can be set i.e. Disabled /
Enabled.
Note: When set as Enabled.
Press the Right arrow key () to move to the next option.
W1 Residual OC
3Io>1 Curve
Definite Time
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>1 Curve can be set i.e. Definite
Time / IEC S Inverse / ST Inverse 1.3S / IEC V Inverse / IEC
E Inverse / UK LT Inverse / IEEE M Inverse / IEEE V Inverse /
IEEE E Inverse / US Inverse / US ST Inverse.
Note: When set as Definite Time Curve.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Residual OC
3Io>1
1.00
0.05 – 35.00 xIn
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>1 can be set.
The setting range is from 0.05 to 35.00 xIn in step of 0.01 xIn.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Residual OC
t 3Io>1 DT Delay
1.00 s
Range 0 – 100s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the t3Io>1 DT Delay can be set.
The setting range is from 0 (Inst) to 100 sec in step of
0.01sec.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Residual OC
3Io>1 D/O Char
DT
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 3Io>1 D/O Char can be set i.e. Disabled /
DT
Note: If Disabled the D/O Characteristics function is blocked.
