Ashida ADR233B - Page 374

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 374 of 479
ADR233B
Note: When set as Enabled
Press the Right arrow key () to move to the next option.
V/Hz – 1 Protection
V/Hz Level 1
105%
Range 100 – 200%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the V/Hz Level 1 Can be set.
The setting range is from 100% to 200% in step of 1%
Press the Minus / Down arrow key (- /) to move to the next
option.
V/Hz – 1 Protection
tV/Hz Level 1
100.0 s
Range 0.1 – 400s
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tV/Hz Level 1 can be set.
The setting range is from 0.1 to 400s in step of 0.1s
Press the Minus / Down arrow key (- /) to move to the next
option.
V/Hz – 1 Protection
tReset V/HzLevel 1
5 s
Range 1 – 400s
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tReset V/HzLevel 1 can be set.
The setting range is from 1 to 400s in step of 1s
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

