ADR233B
option.
IF IDMT
W1 Sequence OC
Seq.I>1 D/O TMS
1.000
Range 0.025 – 1.2
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Seq.I>1 D/O TMS can be set.
The setting range is from 0.025 to 1.2 in step of 0.001
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Sequence OC
Seq.I>1 2H BLK
Enabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Seq.I>1 2H BLK can be set i.e. Disabled
/ Enabled.
Note: If Disabled the Seq.I>1 2H BLK function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF Enabled
W1 Sequence OC
Seq.I>1 2H Thresh
5 %
Range 5 – 70%
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Seq.I>1 2H Thresh can be set.
The setting range is from 5 to 70% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Sequence OC
Seq.I>1 UB2H
10.0 A
4.0 – 32.0 xIn
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Seq.I>1 UB2H can be set.
The setting range is from 4.0 to 32.0 xIn in step of 0.1 xIn.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
