ADR233B
W1 Sequence OC
Seq.I>1 Curve
IEEE M Inverse
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Seq.I>1 Curve can be set i.e. Definite
Time / IEC S Inverse / ST Inverse 1.3S / IEC V Inverse / IEC
E Inverse / UK LT Inverse / IEEE M Inverse / IEEE V Inverse /
IEEE E Inverse / US Inverse / US ST Inverse.
Note: When set as IEEE M Inverse
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Sequence OC
Seq.I>1
0.10 A
0.10 – 2.00 xIn
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Seq.I>1 can be set.
The setting range is from 0.10 to 2.00 xIn in step of 0.01 xIn.
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Sequence OC
Seq.I>1 Time Dial
1.00
Range 0.01 – 100
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Seq.I>1 Time Dial can be set.
The setting range is from 0.01 to 100 in step of 0.01
Press the Minus / Down arrow key (- /) to move to the next
option.
W1 Sequence OC
Seq.I>1 D/O Char
DT
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Seq.I>1 D/O Char can be set i.e.
Disabled / DT / IDMT.
Note: If Disabled the D/O Characteristics function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF DT
W1 Sequence OC
t Seq.I>1 D/O Delay
0.01 S
Range 0 – 100s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the t Seq.I>1 D/O Delay can be set.
The setting range is from 0s to 100s in step of 0.01s
Press the Minus / Down arrow key (- /) to move to the next
