ADR233B
Equipment Data
Ph Differential

REF
Phase OC
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Ph Differential.
Password protected window for “Ph Differential” setting i.e.
Ph Differential Disabled/Enabled, (Is>1, Slope1, Is>2,
Slope2, tIs>, IHs>1, IHs>2) Hrm BLK Criteria Disabled
/Blocked/Restrain Hrm BLK Mode (2nd Hrm Threshold and
4th Hrm Threshold, Cross blocking & t Cross blocking) 5th
Hrm Diff BLK Disabled/Enabled (5H Diff Threshold & t 5th
Hrm)
Press the Right arrow key () to move to the next option.
Ph Differential
Ph Differential
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Ph Differential can be set i.e. Disabled /
Enabled.
Press the Right arrow key () to move to the next option.
Ph Differential
Is>1
0.2 pu
Range 0.1 – 2.5pu
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Is>1 can be set.
The setting range is from 0.1 to 2.5pu in step of 0.1pu.
Press the Minus / Down arrow key (- /) to move to the next
option.
Ph Differential
Slope1
30 %
Range 10 – 150%
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Slope1 can be set.
The setting range is from 10 to 150% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
Ph Differential
Is>2
1.0 pu
Range 0.1 – 10pu
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Is>2 can be set.
The setting range is from 0.1 to 10pu in step of 0.1pu.
Press the Minus / Down arrow key (- /) to move to the next
option.
