ADR233B
W2 – Ibc ANG :
0 Deg
W2 – Ica MAG :
0 A
This window shows angle of Phase BC Current and
Secondary Current in Phase CA of Winding 2 (W2).
Press the Minus / Down arrow key (- /) to move to the next
option.
W2 – Ica ANG :
0 Deg
W2 – I1 P MAG :
0 A
This window shows angle of Phase CA Current and Primary
Current of Positive sequence component of Winding 2 (W2).
Press the Minus / Down arrow key (- /) to move to the next
option.
W2 – I2 P ANG :
0 Deg
W2 – I1 MAG :
0 A
This window shows Primary Current of Negative sequence
component and Secondary Current of Positive sequence
component of Winding 2 (W2).
Press the Minus / Down arrow key (- /) to move to the next
option.
W2 – I1 ANG :
0 Deg
W2 – I2 MAG :
0 A
This window shows angle of Positive sequence component
and Secondary Current of Negative sequence component of
Winding 2 (W2).
Press the Minus / Down arrow key (- /) to move to the next
option.
W2 – I2 ANG :
0 Deg
W2 – I0 MAG :
0 A
This window shows angle of Negative sequence component
and Secondary Current of Zero sequence component of
Winding 2 (W2).
Press the Minus / Down arrow key (- /) to move to the next
option.
W2 – I0 ANG :
0 Deg
W2 – 3I0 MAG :
0 A
This window shows angle of Zero sequence component and
Secondary Current that is multiplied by three times of Zero
sequence component of Winding 2 (W2).
Press the Minus / Down arrow key (- /) to move to the next
option.
W2 – Ia RMS :
0.00 A
W2 – Ib RMS :
0.00 A
This window shows RMS Current in Phase A and Phase B of
Winding 2 (W2).
Press the Minus / Down arrow key (- /) to move to the next
option.
