Group1 to Group 2 Changeover when Group2 is set as TimeEnabled condition
Step 1: Assign the any binary input to Active G2 setting under AProLogic configuration.
Step 2: G2 setting must be set as “TimeEnabled” under “Setting Group” parameter in Global
Menu.
Step 3: Energise the binary input assigned to Active G2 through the DC supply 24 -230V dc
Group1 is changed to Group 2 setting.
Step 4: After disconnect the dc supply to the binary input assigned to Active G2.
Step 5: The Group2 setting will be changed to group1 setting after the Group Change delay
under setting group parameter
Note: The same procedure to be repeated for remaining three groups
4.3.3 Port F Communication setting
The Communication settings of ADR233B IED are listed the below table which is necessary for
the communication between the IED and Personal computer.
Front port settings.
SL. NO Setting Parameters Setting ranges
1 Unit ID 01
2 Baud Rate 57600
3 Set Parity None
The above settings are used to establish the proper communication between the IED and Relay
Talk V2 software from the Computer. The above settings should be set the same in
configuration for the successful communication.
4.3.4 Port 1 Communication setting
The Port 1 Communication settings of ADR233B IED are listed in the below table which is
necessary for the communication between the IED and Local / SCADA Personal computer.
Port 1 settings.
SL. NO Setting Parameters Setting ranges
1. Unit ID 0001 – 0247
2. IP Address 000.000.000.000
3. Subnet Mask 000.000.000.000
4. Default gateway 000.000.000.000
5. Pri. SNTP 000.000.000.000
6. Sec. SNTP 000.000.000.000
