5 MEASUREMENT SHEET
5.1 Measurement 1
Measurement 1 window displays Voltage, Phase and Neutral (EF) Current, Frequency and
symmetrical components based on the power system network of Transformer.
Parameter Unit Description
W1 – IA MAG = 00000 A Primary current in phase A of Winding 1
W1 – IB MAG = 00000 A Primary current in phase B of Winding 1
W1 – IC MAG = 00000 A Primary current in phase C of Winding 1
W1 – IAB MAG = 00000 A Primary current in phase AB of Winding 1
W1 – IBC MAG = 00000 A Primary current in phase BC of Winding 1
W1 – ICA MAG = 00000 A Primary current in phase CA of Winding 1
W1 – Ia MAG = 0.000 A Secondary current in phase A of Winding 1
W1 – Ia ANG = 0 Degree Angle of Phase current A of winding 1
W1 – Ib MAG = 0.000 A Secondary current in phase B of Winding 1
W1 – Ib ANG = 0 Degree Angle of Phase current B of winding 1
W1 – Ic MAG = 0.000 A Secondary current phase C in winding 1
W1 – Ic ANG = 0 Degree Angle of Phase current C of winding 1
W1 – Iab MAG = 0.000 A Secondary current phase AB in winding 1
W1 – Iab ANG = 0 Degree Angle of Phase current AB of winding 1
W1 – Ibc MAG = 0.000 A Secondary current phase BC in winding 1
W1 – Ibc ANG = 0 Degree Angle of Phase current BC of winding 1
W1 – Ica MAG = 0.000 A Secondary current phase CA in winding 1
W1 – Ica ANG = 0 Degree Angle of Phase current CA of winding 1
W1 – I1 P MAG = 00000 A Primary Positive sequence current of Winding 1
W1 – I2 P MAG = 00000 A Primary Negative sequence current of Winding 1
W1 – I1 MAG = 0.000 A Secondary Positive sequence current of Winding 1
W1 – I1 ANG = 0 Degree Angle of Positive sequence current of winding 1
W1 – I2 MAG = 0.000 A Secondary Negative sequence current of Winding 1
W1 – I2 ANG= 0 Degree Angle of Negative sequence current of winding 1
W1 – I0MAG = 0.000 A Secondary zero sequence current of Winding 1
W1 – I0 ANG = 0 Degree Angle of zero sequence current of winding 1
W1 – 3I0MAG = 0.000 A Secondary residual current of Winding 1
W1 – Ia RMS = 0.000 A Secondary RMS current in phase A of winding 1
