Ashida ADR233B - Page 198

Doc ID : ADR233B/IM/01
Ref ID : ADR233B/IM/CS
Rev No. : 05
Page No. : 198 of 479
ADR233B
VIO-31 1 1 bit R 16231
VIO-32
1
1 bit
R
16232
NOTE: *Available only in M19” model
** Available only in Enhance model
Sr. No. Function
Code
Register No. of
Regs
Format Reg.
Type
Address Map
5 Outputs 05
LED Reset 1 16 bit W 03025
W1_CB Trip 1 16 bit W 03026
W1_CB Close 1 16 bit W 03027
W2_CB Trip 1 16 bit W 03092
W2_CB Close 1 16 bit W 03093
J Out1 1 16 bit W 03028
J Out2 1 16 bit W 03029
J Out3 1 16 bit W 03030
J Out4 1 16 bit W 03031
J Out5 1 16 bit W 03032
J Out6 1 16 bit W 03033
J Out7 1 16 bit W 03034
J Out8 1 16 bit W 03035
K Out1 1 16 bit W 03036
K Out2 1 16 bit W 03037
K Out3 1 16 bit W 03038
K Out4 1 16 bit W 03039
K Out5 1 16 bit W 03040
K Out6 1 16 bit W 03041
K Out7 1 16 bit W 03042
K Out8 1 16 bit W 03043
L Out1* 1 16 bit W 03044
L Out2* 1 16 bit W 03045
L Out3* 1 16 bit W 03046
L Out4* 1 16 bit W 03047
L Out5* 1 16 bit W 03048
L Out6* 1 16 bit W 03049
L Out7* 1 16 bit W 03050
L Out8* 1 16 bit W 03051
M Out1* 1 16 bit W 03052
M Out2* 1 16 bit W 03053
M Out3* 1 16 bit W 03054
