ADR233B
VIO-22 1 16 bit W 03162
VIO-23 1 16 bit W 03163
VIO-24 1 16 bit W 03164
VIO-25 1 16 bit W 03165
VIO-26 1 16 bit W 03166
VIO-27 1 16 bit W 03167
VIO-28 1 16 bit W 03168
VIO-29 1 16 bit W 03169
VIO-30 1 16 bit W 03170
VIO-31 1 16 bit W 03171
VIO-32 1 16 bit W 03172
NOTE: *Available only in M19” model
Sr. No. Function
Code
Register No. of
Regs
Format Reg.
Type
Address Map
6 Parameters 04
W1-IA MAG 2 32 bit Float R 33281-33282
W1-IB MAG 2 32 bit Float R 33283-33284
W1-IC MAG 2 32 bit Float R 33285-33286
IN MAG 2 32 bit Float R 33287-33288
Iref Diff 2 32 bit Float R 33349-33350
Iref Bias 2 32 bit Float R 33351-33352
W2-IA MAG 2 32 bit Float R 33377-33378
W2-IB MAG 2 32 bit Float R 33379-33380
W2-IC MAG 2 32 bit Float R 33381-33382
W1-I1 MAG 2 32 bit Float R 33323-33324
W1-I2 MAG 2 32 bit Float R 33327-33328
W1-I0 MAG 2 32 bit Float R 33331-33332
W2-I1 MAG 2 32 bit Float R 33419-33420
W2-I2 MAG 2 32 bit Float R 33423-33424
W2-I0 MAG 2 32 bit Float R 33427-33428
IA-Diff 2 32 bit Float R 33479-33480
IB-Diff 2 32 bit Float R 33481-33482
IC-Diff 2 32 bit Float R 33483-33484
IA-Bias 2 32 bit Float R 33485-33486
IB-Bias 2 32 bit Float R 33487-33488
IC-Bias 2 32 bit Float R 33489-33490
V MAG 2 32 bit Float R 33689-33690
FREQ 2 32 bit Float R 33743-33744
