Ashida ADR233B - Page 213

Doc ID : ADR233B/IM/01
Ref ID : ADR233B/IM/CS
Rev No. : 05
Page No. : 213 of 479
ADR233B
Sr. No. INF Description GI TYP COT FUN
6 Semantics of INFORMATION NUMBER: Fault list in monitor direction
0
List of Recorded
DR
- 23 31 160
Sr. No. INF Description
7 Semantics of Actual Channel : Used for DR Transmission
ACC Description
1 W1-IA MAG
2 W1-IB MAG
3 W1-IC MAG
4 W1-3I0 MAG
64 W2-IA MAG
65 W2-IB MAG
66 W2-IC MAG
74 IN MAG
90 W2-3I0 MAG
5 V
NOTE: Above is the default assignment of analogue channel & maximum 14 analogue Channels are
available, the user can assign analogue Chanel through Alias.
Sr. No. INF Description GI TYP COT FUN
8 Semantics of INFORMATION NUMBER : System Functions in control direction
0
Initialization of
general interrogation
- 7 9 255
0
Time
synchronization
- 6 8 255
Sr. No. INF Description GI TYP COT FUN
9 Semantics of INFORMATION NUMBER : General commands in control direction
19 LED reset ON 20 20 176
123 W1_CB Trip ON/OFF 20 1,7,9,11, 20 127
125 W1_CB Close ON/OFF 20 1,7,9,11, 20 127
206 W2_CB Trip ON/OFF 20 1,7,9,11, 20 124
207 W2_CB Close ON/OFF 20 1,7,9,11, 20 124
92
J Out1
ON/OFF 20 1, 7, 9, 11 127
