Doc ID : ADR233B/IM/01
Ref ID : ADR233B/IM/CS
Rev No. : 05
Page No. : 216 of 479
ADR233B
NOTE: *Available only in M19” model
7.4 IEC 61850
This document provides a proposal of mapping Ashida relay process data into IEC61850 server
objects.
The list of application functions of the Ashida relays is derived from the information specified as
the project requirements in the document “IEC61850 Server for Ashida Electronics Preliminary
Requirements Specification”. This document was approved by Ashida Electronics in October
2009 as the basis for the offer.
7.4.1 Protocol map
DiffL1 Differential Protection (87)
Data Attribute
Dataset
IAPDIF1$ST$OpCntRs$stVal dchg
IAPDIF1$ST$Str$general dchg
IAPDIF1$ST$Op$general dchg
DiffL2 Differential Protection (87)
Data Attribute Dataset
IBPDIF2$ST$OpCntRs$stVal dchg
IBPDIF2$ST$Str$general dchg
IBPDIF2$ST$Op$general dchg
DiffL3 Differential Protection (87)
Data Attribute Dataset
ICPDIF3$ST$OpCntRs$stVal dchg
ICPDIF3$ST$Str$general dchg
ICPDIF3$ST$Op$general dchg
Restrain DiffL1 Differential Protection (87)
Data Attribute Dataset
IAHS1PDIF4$ST$OpCntRs$stVal dchg
IAHS1PDIF4$ST$Str$general dchg
IAHS1PDIF4$ST$Op$general dchg
