ADR233B
W2 Seq>3 Sequence Overcurrent Stage3
Data Attribute Dataset
W2SQ3PTOC12$ST$OpCntRs$stVal dchg
W2SQ3PTOC12$ST$Str$general dchg
W2SQ3PTOC12$ST$Op$general dchg
V< Under-Voltage (27)
Data Attribute Dataset
UV1PTUV1$ST$OpCntRs$stVal dchg
UV1PTUV1$ST$Str$general dchg
UV1PTUV1$ST$Op$general dchg
V> Over-Voltage (59)
Data Attribute Dataset
OV1PTOV1$ST$OpCntRs$stVal dchg
OV1PTOV1$ST$Str$general dchg
OV1PTOV1$ST$Op$general dchg
V/Hz-1 Protection Stage1
Data Attribute Dataset
VbyHz1PVPH1$ST$Str$general dchg
VbyHz1PVPH1$ST$Op$general dchg
V/Hz-2 Protection Stage2
Data Attribute Dataset
VbyHz2PVPH2$ST$Str$general dchg
VbyHz2PVPH2$ST$Op$general dchg
V/Hz-3 Protection Stage3
Data Attribute Dataset
VbyHz3PVPH3$ST$Str$general dchg
VbyHz3PVPH3$ST$Op$general dchg
V/Hz-4 Protection Stage4
Data Attribute Dataset
VbyHz4PVPH4$ST$Str$general dchg
VbyHz4PVPH4$ST$Op$general dchg
